P. 87
Manicotto da maschio a femmina D int
con guarnizione.
Junction from male to female L
with seal.
120 Senso Fumi Direction of smoke
L 1
D
est
Cod. D D L L
int est 1
OL0160561 80 81 60 50 4
OL0160562 100 101 60 50 4
OL0160563 120 121 60 50 4
OL0160564 130 131 60 50 4
OL0160565 140 141 60 50 2 OLI ex S.P. inox
OL0160566 150 151 60 50 2
OL0160567 160 161 60 50 2
OL0160568 180 181 60 50 2
OL0160569 200 201 60 50 2
OL0160578 220 221 60 50 1
OL0160570 250 251 60 50 1
Manicotto da maschio liscio a D
femmina sistema OLI ex. int
Smooth male junction to female L
Senso Fumi Direction of smoke
OLIflex system.
120
D est
Cod. D D L
int est
OL0160581 80 81 60 4
OL0160582 100 101 60 4
OL0160583 120 121 60 4
OL0160584 130 131 60 4
OL0160585 140 141 60 2
OL0160586 150 151 60 2
OL0160587 160 161 60 2
OL0160588 180 181 60 2
OL0160589 200 201 60 2
OL0160598 220 221 60 1
OL0160590 250 251 60 1
www.oli-world.com 85
