RITEGNO / VALVOLE DI FONDO CAPITOLO 3.5

2
DIMENSIONI D’INGOMBRO

104 104 P

3

A B C Peso Kv A B C Peso Kv 4
3
" mm mm mm kg m /h " mm mm mm kg m /h
3
3/4 20/27 64,5 34 0,03 8,0 3/4 20/27 64,5 34 0,03 8,0
1 26/34 78,5 40 0,04 11,9 1 26/34 78,5 40 0,04 11,9
1 1/4 33/42 97,0 49 0,07 20,0
1 1/4 33/42 97,0 49 0,07 20,0
5

290 290 X
297
6

7
A B C Peso Kv A B C Peso Kv
3
3
" mm mm mm kg m /h " mm mm mm kg m /h
1/4 8/13 52,5 20 0,060 2,00 1/4 8/13 52,5 19 0,080 2,00
3/8 12/17 54,0 20 0,075 3,13 3/8 12/17 54,0 19 0,080 3,13
1/2 15/21 66,0 24 0,125 5,00 1/2 15/21 66,0 27 0,130 5,00 8
3/4 20/27 73,0 30 0,200 8,23 3/4 20/27 73,0 30 0,220 8,23
1 26/34 94,0 38 0,200 12,07 1 26/34 94,0 38 0,370 12,07
1 1/4 33/42 105,0 47 0,430 23,00 1 1/4 33/42 105,0 47 0,470 23,00
1 1/2 40/49 120,0 53 0,650 30,00 1 1/2 40/49 127,0 53 0,750 30,00
9
2 50/60 156,0 66 1,050 46,60 2 50/60 156,0 66 1,010 46,60

190 290 D
290 P 10
297 D

schema 1 schema 2
Ø 3/4 – 1 1/4 Ø 1
1 1/2 - 2 11

A B C Peso Kv
A B C Peso Kv
3
" mm mm mm kg m /h
" mm mm mm kg m /h
3
3/8 12/17 54 23 0,018 3,13 12
1 1/2 40/49 148 53 0,320 30,6
1/2 15/21 66 28 0,030 5,00
2 50/60 179 66 0,820 48,5
3/4 20/27 80 34 0,043 8,23
1 26/34 100 44 0,075 12,07
