18 COLLETTORI DI DISTRIBUZIONE DA BARRA
BRASS BAR DISTRIBUTION MANIFOLDS
Utilizzabili con cassetta 1810, 1812, 1920-1930 e 1939-1940 (pag. 342)
Use with box 1810, 1812, 1920-1930 and 1939-1940 (pag. 342)
3030 1290
3031 Raccordo maschio con attacco
3032 G1/2” per collettori da barra con
O-ring
Collettore da barra in ottone Fitting male with O-ring, G1/2”
CW617N con interasse 50 mm e for brass manifolds
uscite 1/2” femmina Foro 3/8”
su lato opposto 1/2” 3/4”
Brass bar manifold made of 16 18
CW617N. Distance between
centres 50 mm with 1/2” female
3/8” bore on the opposite side
Codice Tipo Prezzo € Conf.
Code Size Price € Unit/Box
164 0038 G1/2” - 1/2”(ø16) 10/300
164 0020 G1/2” - 3/4”(ø18) 10/300
Codice Mandata N. vie Uscite Prezzo € Conf.
Code Delivery Ways Outlets Price € Unit/Box
197 0026 3/4”G 2 1/2”G 1/70 1450
197 0070 3/4”G 3 1/2”G 1/45 Raccordo diritto maschio con
197 0076 3/4”G 4 1/2”G 1/30 attacco G1/2” con O-Ring, tubo
PE-X per collettori barra
197 0087 3/4”G 5 1/2”G 1/25 Straight fitting male with
197 0092 3/4”G 6 1/2”G 1/35 O-ring G1/2” PE-X pipe for bar
manifolds
197 0101 3/4”G 7 1/2”G 1/15
Codice Tipo Prezzo € Conf.
197 0100 3/4”G 8 1/2”G 1/15 Code Size Price € Unit/Box
197 0099 3/4”G 9 1/2”G 1/10 140 0636 G1/2” - 14 x 2,0 10/250
197 0107 3/4”G 10 1/2”G 1/25 140 0239 G1/2” - 16 x 2,0 10/250
140 0090 G1/2” - 16 x 2,2 10/250
197 0063 1”G 2 1/2”G 1/45
140 0248 G1/2” - 20 x 2,0 5/150
197 0036 1”G 3 1/2”G 1/35
140 0174 G1/2” - 20 x 2,8 5/150
197 0032 1”G 4 1/2”G 1/20
197 0034 1”G 5 1/2”G 1/20
197 0047 1”G 6 1/2”G 1/20
197 0050 1”G 7 1/2”G 1/20
197 0037 1”G 8 1/2”G 1/20
197 0049 1”G 9 1/2”G 1/8
197 0078 1”G 10 1/2”G 1/8
197 0084 1”G 11 1/2”G 1/8
197 0073 1”G 12 1/2”G 1/8
197 0102 1”1/4 G 2 1/2”G 1/30
197 0094 1”1/4 G 3 1/2”G 1/20
197 0085 1”1/4 G 4 1/2”G 1/12
197 0083 1”1/4 G 5 1/2”G 1/12
197 0067 1”1/4 G 6 1/2”G 1/15
197 0072 1”1/4 G 7 1/2”G 1/15
197 0066 1”1/4 G 8 1/2”G 1/15
197 0090 1”1/4 G 9 1/2”G 1/5
197 0095 1”1/4 G 10 1/2”G 1/5
197 0108 1”1/4 G 11 1/2”G 1/5
197 0098 1”1/4 G 12 1/2”G 1/5
