Elemento controllo fumi con tappo D int
e termometro. D int L
Smoke sampling element with cap L 100
and thermometer. 100
D 10 H
H tot
tot D 80 80
70 100
L 140 L 1
1
D
est D est
Dal Ø 80 al Ø 250 mm Dal Ø 300 al Ø 400 mm
From Ø 80 to Ø 250 mm From Ø 300 to Ø 400 mm
Cod. D D H L L
int est tot 1
OL0160364 130 131 328 60 50 2
OL0160365 140 141 328 60 50 2
OL0160366 150 151 328 60 50 2 OLI ex S.P. inox
OL0160367 160 161 328 60 50 1
OL0160368 180 181 328 60 50 1
OL0160369 200 201 328 60 50 1
OL0160378 220 221 328 60 50 1
OL0160370 250 251 328 60 50 1
Portello d’ispezione per D int D int
combustione solidi temperatura L L
no a 600°C. T600 P1 D.
Inspection element with door for H H u H tot H u
solid combustible temperature up tot H H
to 600°C. T600 P1 D.
H 1
H 1
D D est
est
Dal Ø 80 al Ø 250 mm Dal Ø 300 al Ø 400 mm
From Ø 80 to Ø 250 mm From Ø 300 to Ø 400 mm
Cod. D D H H L H H
int est tot u 1
OL0160814 130 131 395 345 60 175 115 1
OL0160815 140 141 395 345 60 175 115 1
OL0160816 150 151 395 345 60 175 115 1
OL0160817 160 161 395 345 60 175 115 1
OL0160818 180 181 395 345 60 175 115 1
OL0160819 200 201 395 345 60 175 115 1
OL0160828 220 221 395 345 60 175 115 1
OL0160820 250 251 395 345 60 175 115 1
OL0160821CL 300 301 490 440 60 280 165 1
OL0160822CL 350 351 490 440 60 280 165 1
OL0160823CL 400 401 490 400 60 280 165 1
Attenzione: non installare con caldaie a condensazione o funzionamento ad umido.
Attention: do not install with condensation boilers or wet systems.
Aggiungere fascetta stringitubo. - Hose locking band to add. (pag. 115).
