Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
Ventilatori: J
SEER - 12/7 (EN14825: 2018) (1)
° W/W - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2)
A W/W 4,56 4,56 4,56 4,55 4,57 4,56 4,56 4,56 4,57 4,56 4,56 4,56 4,57

E W/W 4,58 4,59 4,59 4,59 4,59 4,59 4,59 4,59 4,60 4,58 4,59 - -
SEER
L W/W 4,55 4,56 4,55 4,56 4,56 4,57 4,56 4,57 4,56 4,56 4,56 4,56 4,56
N W/W 4,60 4,60 4,60 4,60 4,60 4,61 4,60 4,61 - - - - -
U W/W 4,59 4,59 4,60 4,60 4,60 4,60 4,59 4,60 4,60 4,59 4,59 - -
° % - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2) - (2)
A % 179,50 179,40 179,40 179,10 179,80 179,40 179,40 179,20 179,60 179,20 179,40 179,50 179,70
E % 180,30 180,60 180,70 180,60 180,40 180,40 180,60 180,50 180,90 180,20 180,40 - -
Efficienza stagionale

L % 179,00 179,20 179,10 179,20 179,40 179,60 179,40 179,60 179,30 179,20 179,50 179,40 179,50
N % 180,80 181,00 181,10 181,00 181,10 181,20 180,80 181,40 - - - - -
U % 180,40 180,60 180,80 180,90 180,90 180,80 180,60 180,80 180,90 180,60 180,60 - -
SEPR - (EN 14825: 2018) (3)
° W/W 5,51 5,52 5,53 5,52 5,53 5,52 5,52 5,64 5,51 5,54 5,55 5,51 5,54
A E W/W 5,56 5,60 5,60 5,57 5,60 5,60 5,57 5,66 5,61 5,71 5,69 5,62 5,68
ARIA-ACQUA SEPR L N W/W 5,51 5,53 5,55 5,54 5,56 5,55 5,52 5,64 5,61 5,68 5,66 5,63 5,68 ARIA-ACQUA
5,62
5,60
5,60
5,75
W/W
5,75
5,70
5,70
5,90
5,85
-
-
5,77
5,74
5,65
-
-
W/W
-
-
5,67
5,79
5,71
5,73
5,71
-
5,79
5,65
W/W
U
(1) Calcolo eseguito con portata d’acqua FISSA e temperatura d’uscita VARIABILE. 5,85 5,81 5,85 5,73 5,71 5,72 5,84 5,93 5,98 5,82 5,87 - -
(2) Non conformi al regolamento 2016/2281 UE per applicazioni di comfort 12°C / 7°C
(3) Calcolo eseguito con portata d’acqua FISSA.
DATI ELETTRICI
Taglia 1402 1602 1802 2002 2202 2352 2502 2652 2802 3002 3202 3402 3602 3902

Dati elettrici
° A 229,0 257,0 284,0 324,0 357,0 379,0 400,0 433,0 458,0 466,0 466,0 514,0 562,0 619,0
A,L A 235,0 263,0 291,0 324,0 364,0 385,0 406,0 437,0 462,0 462,0 462,0 516,0 564,0 619,0
Corrente massima (FLA)
E,U A 235,0 263,0 297,0 330,0 364,0 391,0 413,0 444,0 468,0 468,0 468,0 523,0 571,0 625,0
N A 242,0 270,0 303,0 337,0 370,0 398,0 419,0 450,0 475,0 475,0 475,0 529,0 583,0 644,0
° A 251,0 292,0 335,0 380,0 403,0 450,0 467,0 502,0 512,0 521,0 521,0 645,0 685,0 814,0
A,L A 257,0 299,0 342,0 380,0 409,0 456,0 473,0 507,0 517,0 517,0 517,0 647,0 687,0 814,0
Corrente di spunto (LRA)
E,U A 257,0 299,0 348,0 386,0 409,0 462,0 480,0 513,0 523,0 523,0 523,0 653,0 693,0 821,0
N A 263,0 305,0 354,0 392,0 415,0 469,0 486,0 519,0 529,0 529,0 529,0 660,0 706,0 839,0
Taglia 4202 4502 4802 5202 5602 6002 6402 6503 6703 6903 7203 8403 9603
Dati elettrici
° A 667,0 714,0 753,0 805,0 848,0 882,0 924,0 949,0 997,0 1084,0 1137,0 1266,0 1368,0
A,L A 667,0 712,0 751,0 813,0 865,0 913,0 947,0 955,0 1003,0 1094,0 1133,0 1268,0 1406,0
Corrente massima (FLA)
E,U A 679,0 718,0 770,0 813,0 862,0 902,0 943,0 968,0 1022,0 1100,0 1145,0 - -
N A 692,0 743,0 789,0 838,0 887,0 921,0 955,0 987,0 - - - - -

° A 841,0 914,0 936,0 1100,0 1147,0 1259,0 1264,0 1038,0 1065,0 1160,0 1197,0 1446,0 1552,0
A,L A 841,0 911,0 934,0 1108,0 1164,0 1290,0 1287,0 1044,0 1071,0 1170,0 1193,0 1448,0 1590,0
Corrente di spunto (LRA)
E,U A 854,0 918,0 953,0 1108,0 1161,0 1279,0 1283,0 1056,0 1090,0 1176,0 1205,0 - -
N A 866,0 943,0 972,0 1133,0 1186,0 1298,0 1295,0 1076,0 - - - - -

NSM-1402-9603-CO_I_CE50_14 www.aermec.com 561
