aquatherm blue pipe Giunti a sella

D Giunto a sella filettato maschio Materiale: fusiolen® PP-R / ottone
R SW Standard: DIN 16962, DIN EN ISO 15874
SDR 6 / 7,4 / 9 / 11 / 17,6 - per montaggio senza pressione Colore: verde
z 2 Articolo no. D1 d l D z2 R SW kg Conf. GP Prezzo [€]
Saldatura a tasca da un lato
l
1030040102 * 40 25 55,0 38,5 16,0 1/2“ 21 0,088 5 A 12,22
1030050108 50 25 55,0 38,5 16,0 1/2“ 21 0,090 5 A 12,22
1030063114 63 25 55,0 38,5 16,0 1/2“ 21 0,089 5 A 12,22
D1
d 1030075121 75 25 55,0 38,5 16,0 1/2“ 21 0,097 5 A 12,22
1030090129 90 25 55,0 38,5 16,0 1/2“ 21 0,090 5 A 12,22
1030110137 110 25 55,0 38,5 16,0 1/2“ 21 0,089 5 A 12,22
1030125145 125 25 55,0 38,5 16,0 1/2“ 21 0,092 5 A 12,22
1030160153 160 25 55,0 38,5 16,0 1/2“ 21 0,092 5 B 11,86
1030040103 * 40 25 56,0 43,5 17,0 3/4“ 24 0,107 5 A 17,25
1030050109 50 25 56,0 43,5 17,0 3/4“ 24 0,110 5 A 17,25
1030063115 63 25 56,0 43,5 17,0 3/4“ 24 0,109 5 A 17,25
1030075122 75 25 56,0 43,5 17,0 3/4“ 24 0,109 5 A 17,25
1030090130 90 25 56,0 43,5 17,0 3/4“ 24 0,110 5 A 17,25
1030110138 110 25 56,0 43,5 17,0 3/4“ 24 0,110 5 A 17,25
1030125146 125 25 56,0 43,5 17,0 3/4“ 24 0,112 5 A 17,25
1030160154 160 25 56,0 43,5 17,0 3/4“ 24 0,112 5 B 16,74
*non utilizzare con aquatherm blue pipe OT

D Giunto a sella filettato femmina Materiale: fusiolen® PP-R / acciaio inox
R SDR 6 / 7,4 / 9 / 11 / 17,6 - per montaggio senza pressione Standard: DIN 16962, DIN EN ISO 15874
Colore:
verde
Articolo no. D1 d l D z2 R kg Conf. GP Prezzo [€]
z 2
Saldatura a tasca da un lato
l
1030040104 ** 40 25 39,0 38,5 16,0 1/2“ 0,062 1 A 29,40
1030050110 50 25 39,0 38,5 16,0 1/2“ 0,064 1 A 29,40
D1
d 1030063116 63 25 39,0 38,5 16,0 1/2“ 0,064 1 A 29,40
1030075123 75 25 39,0 38,5 16,0 1/2“ 0,064 1 A 29,40
1030090131 90 25 39,0 38,5 16,0 1/2“ 0,064 1 A 29,40
1030110139 110 25 39,0 38,5 16,0 1/2“ 0,069 1 A 29,40
1030125147 125 25 39,0 38,5 16,0 1/2“ 0,065 1 A 29,40
1030160155 160 25 39,0 38,5 16,0 1/2“ 0,066 1 B 28,54
1030250161 200-250 25 39,0 38,5 16,0 1/2“ 0,065 1 B 28,54
1030040105 40 25 39,0 43,5 21,0 3/4“ 0,082 1 A 36,58
D 1030050111 50 25 39,0 43,5 21,0 3/4“ 0,074 1 A 36,58
R SW
1030063117 63 25 39,0 43,5 21,0 3/4“ 0,073 1 A 40,62
1030075124 75 25 39,0 43,5 21,0 3/4“ 0,074 1 A 38,61
z 2
1030090132 90 25 39,0 43,5 21,0 3/4“ 0,074 1 A 38,61
l
1030110140 110 25 39,0 43,5 21,0 3/4“ 0,083 1 A 38,61
1030125148 125 25 39,0 43,5 21,0 3/4“ 0,074 1 A 38,61
D1 1030160156 160 25 39,0 43,5 21,0 3/4“ 0,076 1 B 37,48
d
1030250162 200-250 25 39,0 43,5 21,0 3/4“ 0,084 1 B 37,48
1030075125 * 75 32 43,0 60,0 22,0 1“ 0,234 1 A 61,90
1030090133 * 90 32 43,0 60,0 22,0 1“ 0,235 1 A 61,90
1030110141 * 110 32 43,0 60,0 22,0 1“ 0,236 1 A 61,90
1030125149 * 125 32 43,0 60,0 22,0 1“ 0,235 1 A 61,90
1030160157 * 160 32 43,0 60,0 22,0 1“ 0,238 1 B 60,10
1030250163 * 200-250 32 43,0 60,0 22,0 1“ 0,237 1 B 60,10
*con sede esagonale esterna
**non utilizzare con aquatherm blue pipe OT
