Informazioni utili al dimensionamento Useful information for sizing
Realizzazione di un camino/canna fumaria destinato/a Construction of a chimney/flue pipe meant to the discharge
all’evacuazione dei prodotti della combustione di caldaie of combustion products of condensation C Type boilers.
Tipo C “a condensazione”.
Boiler data:
Dati del generatore:
Useful output [KMV]: useful or nominal thermal output.
Potenza utile [KMV]: valore della potenza termica utile Casing loss [%]: heat loss of boiler from the furnace
o nominale. casing when boiler Is off.
Perdite al mantello [%]: dispersione termica della Flue gas velocity [kg/s]: maximum flow rate of gas from
caldaia attraverso il suo involucro a bruciatore spento. boiler.
Portata fumi [kg/s]: portata massima fumi in uscita dal CO [%]: percentage content of CO in the gas.
2
2
generatore di calore. Thermal efficiency [%]: ratio between the useful thermal
CO [%]: tenore percentuale diCO nei fumi. output and the thermal output of the device expressed
2 2
Rendimento utile [%]: rapporto tra la potenza termica as a percentage.
utile e la potenza termica al focolare espresso in Pressure [Pa]: for all boilers, with the exception of C
percentuale. type boilers, this is a synonym of the required supply
Pressione [Pa]: per tutte le caldaie tranne le tipo C è pressure to the boiler and is equal to the pressure loss
sinonimo di pressione di alimentazione necessaria in the boiler. For all C type boilers it is a synonym of
al generatore ed equivale alle perdite di carico nel the available pressure and is indicated with a negative
generatore di calore. Per tutte le caldaie di tipo C è value.
sinonimo di prevalenza disponibile e va inserito con Gas temperature [°C]: temperature of gas going out of
segno negativo. the boiler.
Temperatura fumi [°C]: temperatura dei fumi in uscita Diameter gas outlet [mm].
dal generatore di calore.
Diametro uscita fumi [mm].
