P. 26
Densità: Density:
0,941 g/cm³ 0.941 g/cm³
Permeabilità ossigeno: Oxygen permeability:
(ISO 17455) <0,01 mgO /m day (ISO 17455) <0,01 mgO /m day
2
2
2
2
Temperatura massima: Maximum temperature:
in esercizio continuo +70°C in continuous operation +70°C
Temperatura minima: Minimum temperature:
-45°C (sotto gli 0°C è necessaria l'additivazione con glicole -45°C (below 0°C, glycol or antifreeze additives are re-
o antigelo) quired)
Pressione massima: Maximum pressure:
6 bar a 70°C 6 bar at 70°C
Conducibilità termica: Thermal conductivity:
W/mK 0,40 0.40 W/mK
Coefficiente di dilatazione termica lineare: Coefficient of linear thermal expansion:
mm/mK 0,180 0.180 mm/mK
Rugosità interna: Internal roughness:
mm 0,007 0.007 mm
Raggio di curvatura: Bending radius:
6 volte il diametro 6 x diameter
Marcatura: Marking:
dicitura stampigliata lungo la direttrice con un intervallo wording printed along pipe length with dashed spacing
tratteggiato su ogni metro lineare, come di seguito: each metre as follows:
m. <nnn> aquatechnik - polipert - Testato per sistema m. <nnn> aquatechnik - polipert - Testato per sistema
Safety - dd x ss - PE-RT-EVOH-PE-RT - Data di produzione: Safety - dia x thk - PE-RT-EVOH-PE-RT - Production date:
HH:MM GG/GG/AA - Data tubo di servizio: GG/MM/AA - HH:MM DD/MM/YY - Date service pipe: DD/MM/YY -
(riferimenti normativi e di certificazione prodotto) - EK (standard and product certification references) - EK <xxx>
<xxx>
Specifiche prodotto Tubi polipert in rotoli Polipert pipes in coils
Product specifications A Articolo DN/OD* Ø int. Spessore DN Cont. H20 Peso** Rotolo Bancale
Item int. Ø Thickness DN H O cont. Weight** Roll Pallet
2
mm mm mm l/m Kg/m m m
75005 16 12 2 12 0,113 0,080 250 4500
75007 16 12 2 12 0,113 0,080 500 5000
75011 20 16 2 15 0,201 0,110 250 3000
*Il valore DN/OD riportato nelle tabelle è relativo a tubazioni *The DN/OD value shown in the tables refers to metal pipes and
in materiale metallico e vuole indicare la tubazione corrispon- indicates the corresponding plastic pipe.
dente in materiale polimerico.
**NB: i pesi riportati sono quelli reali del manufatto rilevati **NB: the indicated weights are the physical weights of the
durante le fasi di produzione, pertanto possono risentire delle item during the production phases, therefore they can change
variazioni dimensionali del prodotto. according to the dimensional variations of the product.
Classi di applicazione In conformità alla norma ISO 22391, i tubi della serie In accordance with international standard ISO 22391,
Application classes polipert possono essere impiegati, in relaziona alla classe the polipert series of pipes may be used in relation to the
di applicazione, alle condizioni di temperatura e durata class of application, temperature and lifetime specified in
specificate in tabella. the table.
Classe Temperatura Temperatura Temperatura
di applicazione operativa Durata max operativa Durata malfunzionamento Durata Applicazione tipica
Application class Operating Duration Max operating Duration Malfunction Duration Typical application
temperature temperature temperature
°C anni years °C anni years °C ore hours
Riscaldamento radiante
4 a 20 + 40 + 60 2,5 + 20 + 25 70 2,5 100 100 e impianti a bassa temperatura
Floor heating and
low temperature installations
