Specifiche prodotto La vasta gamma diametrale e i vantaggi offerti da queste The wide range of diameters and advantages provided by
tubazioni consentono l’utilizzo dei tubi multi-calor nei più these pipes enables the use of multi-calor pipes in com-
Product specifications diversificati campi applicativi del settore civile, industriale mercial, industrial and domestic applications, for sanitary,
e terziario, per impianti idrosanitari, impianti di riscal- heating, cooling, irrigation and compressed air systems.
damento, raffrescamento, irrigazione e aria compressa.
Tubi multi-calor in verghe Multi-calor pipes in rods
Spessore Quantità
Articolo Ø int. Spessore allumino DN Cont. H20 Peso** Verga per fascio
Item DN/OD* int. Ø Thickness Aluminum DN H O cont. Weight** Rod Quantity
2
thickness per bundle
mm mm mm mm l/m Kg/m m m
74154 16 12 2 0,30 12 0,113 0,113 4 60
74156 20 16 2 0,40 15 0,201 0,156 4 40
74158 26 20 3 0,58 20 0,314 0,286 4 40
74160 32 26 3 0,75 25 0,531 0,390 4 32
74162 40 33 3,5 0,80 32 0,854 0,545 4 20
74164 50 42 4 1,00 40 1,383 0,833 4 20
74166 63 54 4,5 1,20 50 2,286 1,232 4 12
74168 75 65 5 1,35 65 3,312 1,603 4 8
74170 90 76 7 1,35 80 4,528 2,403 4 4
Tubi multi-calor in rotoli Multi-calor pipes in coils
Spessore
Articolo Ø int. Spessore allumino DN Cont. H20 Peso** Rotolo Bancale
Item DN/OD* int. Ø Thickness Aluminum DN H O cont. Weight** Roll Pallet
2
thickness
mm mm mm mm l/m Kg/m m m
74002 14 10 2 0,30 10 0,077 0,097 100 6400
74004 16 12 2 0,30 12 0,113 0,113 100 5200
74006 18 14 2 0,30 15 0,154 0,130 100 3200
74008 20 16 2 0,40 15 0,201 0,156 100 3000
74010 26 20 3 0,58 20 0,314 0,286 50 1200
74012 32 26 3 0,75 25 0,531 0,390 50 800
*Il valore DN/OD riportato nelle tabelle
è relativo a tubazioni in materiale me-
tallico e vuole indicare la tubazione
corrispondente in materiale polimerico. Tubi multi-calor isoline in rotoli, rivestiti con guaina Multi-calor isoline pipes in coils, coated with thermal
*The DN/OD value shown in the tables termoisolante insulation
refers to metal pipes and indicates the I tubi in rotoli dei diametri compresi tra i 14 e 32 mm Coiled pipes in reels with diameters ranging from 14 to 32
corresponding plastic pipe. vengono forniti anche in versione preisolata. mm are also supplied in a pre-insulated version.
Il materiale isolante, che costituisce il rivestimento dei The insulating material, which constitutes the coating of
**NB: i pesi riportati sono quelli reali del tubi, è polietilene espanso a celle chiuse avente un fat- the pipe, is a closed-cell polyethylene foam with a water
manufatto rilevati durante le fasi di pro-
duzione, pertanto possono risentire delle tore di resistenza alla diffusione del vapore acqueo vapour diffusion resistance factor of approximately
variazioni dimensionali del prodotto. di circa 5000 e una conducibilità termica pari a l= 5,000 and a thermal conductivity l= 0.040 W/mK.
**NB: the indicated weights are the phy- 0,040 W/mK. A low-density polyethylene film of different colours is
sical weights of the item during the Sullo strato isolante viene poi estrusa una guaina in po- then extruded on the insulating layer.
production phases, therefore they can lietilene a bassa densità di colori differenti.
change according to the dimensional
variations of the product.
Tubi multi-calor in rotoli, con guaina termoisolante Multi-calor pipes in coils, with green thermal insu-
verde lation
Linea dedicata a impianti di riscaldamento ed im- Range for heating systems and high-temperature sa-
pianti idrosanitari ad alta temperatura (contenimento nitary systems (energy containment).
energetico).
Spessore Ø est. tubo Spessore Cont.
Articolo Ø int. Spessore allumino DN rivestito rivestimento H20 Peso** Rotolo Bancale
Item DN/OD* int. Ø Thickness Aluminum DN ext. Ø Insulation H O Weight** Roll Pallet
2
thickness insulated pipe thickness cont.
mm mm mm mm mm mm l/m Kg/m m m
74032 14 10 2 0,30 10 26 6 0,077 0,105 50 1800
74033 16 12 2 0,30 12 28 6 0,113 0,121 25 1700
74034 16 12 2 0,30 12 28 6 0,113 0,121 50 1700
74035 16 12 2 0,30 12 28 6 0,113 0,121 100 1600
74036 18 14 2 0,30 15 30 6 0,154 0,139 50 1700
74037 20 16 2 0,40 15 32 6 0,201 0,166 25 1500
74038 20 16 2 0,40 15 32 6 0,201 0,166 50 1500
74039 20 16 2 0,40 15 32 6 0,201 0,166 100 1400
74040 26 20 3 0,58 20 46 10 0,314 0,320 25 700
74041 26 20 3 0,58 20 46 10 0,314 0,320 50 700
74042 32 26 3 0,75 25 52 10 0,531 0,430 25 350
74043 32 26 3 0,75 25 52 10 0,531 0,430 50 350
